OEM Systems Lighting Control for Vantage 16 AWG 2-Conductor 300V Low Capacitance Cable
16-2C-VAN
Pricing :
Login for Your Price
Or
- 26-strand annealed bare copper conductors
- Semi-rigid PVC insulation
- Twisted, unshielded
- Flame rated PVC jacket
- NEC CMR, CEC CMR FT4, RoHS compliant
- 1000 foot spools
- OEM systems bus cable for lighting control
- Speaker level audio, 70 volt speaker cabling
- Class 2 and class 3 low voltage power
- Instrumentation and control
Specifications
| Product Line: | 16-2C-VAN |
|---|---|
| Description | 2 conductor 16 AWG stranded, twisted, and unshielded cable NEC type CMR and CEC type CMG FT4. Product manufactured compliant to the requirements of UL444 for installations and applications in accordance with NEC articles 725 and 800. |
| Conductor | 16 AWG 26-strand annealed bare copper conductors Diameter: 0.0589" | 1.50mm |
| Electrical | DC resistance: 4.04 Ω / 1000’ | 13.25 Ω/KM Mutual capacitance: 26.7 pF/FT | 87.57 pF/M Impedance: 74 Ω Inductance: 0.15µH/FT | 0.49µH/M Velocity of Propagation: 55% Voltage rating: 300V Maximum current: 6.25A@25°C |
| Insulation | Semi-rigid polyvinyl chloride Wall thickness: 0.016" | 0.41mm Diameter: 0.091" | 2.31mm |
| Regulatory | NEC: CMR 75°C CEC: CMG FT4 60°C EU RoHS-2 2011/65/EU Compliant |
| Color Code | Black, Red |
| Packages | Reel: 1000’ | 305M Weight: 39 Lbs/1000’ | 59 Kg/KM |
| Assembly | 2 conductors twisted Lay length: 3.0" | 80mm 4.0 twists per foot | 12.5 twists per meter |
| Installation | Pull Tension: 42 Lbs | 187 N Bend radius: 2.52" | 64mm unloaded Bend radius: 5.04" | 128mm loaded |
| Construct | Ripcord under jacket |
| Applications | Riser low capacitance lighting bus control Riser commercial and residential speaker level audio General purpose 70V commercial speaker audio General purpose Class 2 and 3 power |
| Shield | N/A |
| Performance | Vantage® Lighting Control Speaker level audio to 50 feet |
| Jacket | Flame rated polyvinyl chloride Colors: Purple with yellow stripe Wall thickness: 0.032" | 0.81mm Diameter: 0.252" | 6.40mm |
| Final Outside Diameter (inches) | 0.252 |
PVC-coated Products; PVC-coated Wires and Cables
WARNING: This product can expose you to chemicals including DINP and/or DEHP, which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov or our information page: California Proposition 65.
