USB 2.0 Hi-Speed Twisted Pair Extender WP Host
Sold Out!
Or
The DigitaLinx DL-USB2 products will extend a Hi-Speed USB 2.0 signal (480 Mbps) up to 100 meters (328 feet). The extenders may be powered on either end for low power devices such as keyboards or mice. For remote devices which require more power, the client side extender will require to be powered. Initial offerings in the product line include a modular USB host transmitter (DL-USB2-H), a modular USB client receiver (DL-USB2-C), a wall plate USB host transmitter (DL-USB2-WP-H), and a wall plate USB receiver (DL-USB2-WP-C). All combinations of host and client are compatible with each other.
- Extends USB High-Speed (480 Mbps) up to 100m (330ft)
- Must be powered by client side
- Uses any Cat5e/6/6A twisted pair cabling
- Supplies 500mA to connected USB device
- Can also be used to extend USB 1.1 signals
- Does not support applications requiring Isochronous data mode. Use DIGI-USB2 for these applications
PVC-coated Products; PVC-coated Wires and Cables
WARNING: This product can expose you to chemicals including DINP and/or DEHP, which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov or our information page: California Proposition 65.
DL-USB2-C
DL-USB2-WP-C
