Product Overview
Features and Benefits
- 105-strand oxygen-free copper conductors
- Semi-rigid PVC insulation
- Twisted, unshielded with paper tape binder
- Semi-pressured flame rated PVC jacket
- NEC CL2, CEC CMG FT4 audio only, RoHS compliant
- 500 foot spool standard
Applications
- Speaker level audio, home theater grade
- High wattage systems and infrastructure
- Class 2 low voltage power
10-2C-EX+-WHT Summary
10-2C-EX+-WHT Diagrams
10-2C-EX+-WHT is comparable to:
| Manufacturer | Part Number |
|---|---|
| ManufacturerBelden | Part Number5T00UP |
| ManufacturerBelden NG | Part Number5T00UP |
| ManufacturerWest Penn | Part NumberHA210 |
Alternatives for 10-2C-EX+-WHT
No equivalent alternates available for 10-2C-EX+-WHT
.Specifications
| Product Line: | 10-2C-EX+ |
|---|---|
| Product Line: Description | 10-2C-EX+2 conductor 10 AWG stranded, twisted, and unshielded cable NEC type CL2 and CEC type CMG FT4 for Audio Only. Product manufactured compliant to the requirements of UL13 for installations and applications in accordance with NEC article 725. |
| Product Line: Conductor | 10-2C-EX+10 AWG 105-strand oxygen free copper conductors Diameter: 0.118" | 3.00mm |
| Product Line: Electrical | 10-2C-EX+DC resistance: 1.07 Ω / 1000’ | 3.51 Ω/KM Mutual capacitance: 46.0 pF/FT | 150.9 pF/M Impedance: 47 Ω Inductance: 0.15µH/FT | 0.49µH/M Velocity of Propagation: 55% Voltage rating: 150V Maximum current: 27.8A@25°C |
| Product Line: Insulation | 10-2C-EX+Semi-rigid polyvinyl chloride Wall thickness: 0.016" | 0.41mm Diameter: 0.150" | 3.81mm |
| Product Line: Regulatory | 10-2C-EX+NEC: CL2 75°C CEC: CMG FT4 For Audio Ωnly 60°C EU RoHS 2002/95/EC Compliant |
| Product Line: Color Code | 10-2C-EX+Black, Red |
| Product Line: Packages | 10-2C-EX+Reel: 1000’ | 305M Weight: 99 Lbs/1000’ | 147 Kg/KM |
| Product Line: Assembly | 10-2C-EX+2 conductors twisted Lay length: 4" | 100mm 3 twists per foot | 10.0 twists per meter |
| Product Line: Installation | 10-2C-EX+Pull Tension: 250 Lbs | 751 N Bend radius: 3.85" | 98mm unloaded Bend radius: 7.70" | 196mm loaded |
| Product Line: Construct | 10-2C-EX+100% Paper tape binder Ripcord under jacket |
| Product Line: Applications | 10-2C-EX+General purpose speaker level audio Non‐plenum 70V commercial speaker audio Non‐Plenum Class 2 power |
| Product Line: Shield | 10-2C-EX+N/A |
| Product Line: Performance | 10-2C-EX+Speaker level audio to 200 feet |
| Product Line: Jacket | 10-2C-EX+Pressure extruded polyvinyl chloride Colors: Natural white Wall thickness: 0.040" | 1.02mm Diameter: 0.385" | 9.78mm |
| Product Line: Final Outside Diameter (inches) | 10-2C-EX+0.385 |
