1000' Black EXTRAFLEX 14 AWG 2-Conductor Heavy-Duty Speaker Cable Reel

14-2C-EX+-BLK


List Product Options

Ordering Options

Pricing

Login for Your Price

Availability


Product Options

Packaging:
Color(s):
Length(s):
Quantity:
Units:
Add to Cart

Have Tech Questions?
California Proposition 65

Product Overview

Features and Benefits

  • 105-strand oxygen-free copper conductors
  • Semi-rigid PVC insulation
  • Twisted, unshielded with paper tape binder
  • Semi-pressured flame rated PVC jacket
  • NEC CL3, CEC CMG FT4 audio only, RoHS compliant
  • 1000 foot spools

Applications

  • Speaker level audio, Home theater grade
  • Best applications below 80 feet
  • Class 2 and 3 low voltage power

14-2C-EX+-BLK Summary

14-2C-EX+-BLK Diagrams

14-2C-EX+-BLK is comparable to:

Manufacturer Part Number
Belden NG 5100UP

Alternatives for 14-2C-EX+-BLK

No equivalent alternates available for 14-2C-EX+-BLK

.

Specifications

PDF Spec Sheet

Product Line:   14-2C-EX+
Description 2 conductor 14 AWG stranded, twisted, and unshielded cable NEC type CL3 and CEC type CMG FT4 for Audio Only. Product manufactured compliant to the requirements of UL13 for installations and applications in accordance with NEC article 725.
Conductor 14 AWG
105-strand oxygen free copper conductors
Diameter: 0.074" | 1.89mm
Electrical DC resistance: 2.58 Ω / 1000’ | 8.46 Ω/KM
Mutual capacitance: 34 pF/FT | 111.52 pF/M
Impedance: 65 Ω
Inductance: 0.17µH/FT | 0.55µH/M
Velocity of Propagation: 55%
Voltage rating: 300V
Maximum current: 8A@25°C
Insulation Semi-rigid polyvinyl chloride
Wall thickness: 0.016" | 0.41mm
Diameter: 0.1063" | 2.7mm
Regulatory NEC: CL3 75°C
CEC: CMG FT4 For Audio Only 60°C
EU RoHS-2 2011/65/EU Compliant
Color Code Black, Red
Packages Reel: 1000’ | 305M
Weight: 71 Lbs/1000’ | 106 Kg/KM
Assembly 2 conductors twisted
Lay length: 4.0" | 100mm
3.0 twists per foot | 10.0 twists per meter
Installation Pull Tension: 67 Lbs | 298 N
Bend radius: 2.87" | 73mm unloaded
Bend radius: 5.74" | 146mm loaded
Construct 100% Paper tape binder
Ripcord under jacket
Applications General purpose speaker level audio
General purpose 70V commercial speaker audio
General purpose Class 2 and 3 power
Shield N/A
Performance Speaker level audio to 80 feet
Jacket Pressure extruded polyvinyl chloride
Colors: White, Green, Pink
Wall thickness: 0.035" | 0.90mm
Diameter: 0.287" | 7.28mm
Final Outside Diameter (inches) 0.287
