1000' Black EXTRAFLEX 16 AWG 4-Conductor Heavy Duty Speaker Cable Reel

16-4C-EX+-BLK


List Product Options

Ordering Options

Pricing

Login for Your Price

Availability


Product Options

Packaging:
Color(s):
Length(s):
Quantity:
Units:
You might also consider this alternate:

Add to Cart

Have Tech Questions?
California Proposition 65

Product Overview

Features and Benefits

  • 105-strand oxygen free copper conductors
  • Semi-Rigid PVC insulation
  • Twisted, unshielded with paper tape binder
  • Semi-pressured flame rated PVC jacket
  • NEC CM, CEC CMG FT4 Audio Only, RoHS compliant
  • 1000 foot spools

Applications

  • Speaker Level Audio, Home theater grade
  • Best applications below 50 feet
  • Class 2 and 3 low voltage power

16-4C-EX+-BLK Summary

16-4C-EX+-BLK Diagrams

16-4C-EX+-BLK is comparable to:

Manufacturer Part Number
Belden 1308A
Belden NG 5202UP
West Penn HA245

Alternatives for 16-4C-EX+-BLK

Part Number Description
14-2C-EX+EXTRAFLEX 14 AWG 2-Conductor Heavy-Duty Speaker Cable

Specifications

PDF Spec Sheet

Product Line:   16-4C-EX+
Description 4 conductor 16 AWG stranded, twisted, and unshielded cable NEC type CMR and CEC type CMG FT4. Product manufactured compliant to the requirements of UL444 for installations and applications in accordance with NEC articles 725 and 800.
Conductor 16 AWG
105-strand oxygen free copper conductors
Diameter: 0.059" | 1.50mm
Electrical DC resistance: 4.02 Ω / 1000’ | 13.18 Ω/KM
Mutual capacitance: 27.3 pF/FT | 89.5 pF/M
Impedance: 73 Ω
Inductance: 0.16µH/FT | 0.52µH/M
Velocity of Propagation: 55%
Voltage rating: 300V
Maximum current: 5.0A@25°C
Insulation Semi-rigid polyvinyl chloride
Wall thickness: 0.016" | 0.41mm
Diameter: 0.091" | 2.32mm
Regulatory NEC: CL3 75°C
CEC: CMG FT4 60°C
EU RoHS-2 2011/65/EU Compliant
Color Code Black, Red, White, Green
Packages Reel: 1000’ | 305M
Reel: 500’ | 152M
Weight: 70 Lbs/1000’ | 105 Kg/KM
Assembly 4 conductors twisted
Lay length: 3.0" | 80mm
4.0 twists per foot | 12.5 twists per meter
Installation Pull Tension: 84 Lbs | 374 N
Bend radius: 2.91" | 74mm unloaded
Bend radius: 5.82" | 148mm loaded
Construct 100% Paper tape binder
Ripcord under jacket
Applications General purpose speaker level audio
General purpose 70V commercial speaker audio
General purpose Class 2 and 3 power
Shield N/A
Performance Speaker level audio to 50 feet
Jacket Pressure extruded polyvinyl chloride
Colors: White, Black, Green, Royal Blue, Pink
Wall thickness: 0.035" | 0.90mm
Diameter: 0.291" | 7.40mm
Final Outside Diameter (inches) 0.291
