1000' Black Line Level Audio Non-Rated Cable for Interconnect Manufacture Reel

INTERFLEX-SD-BLK


List Product Options

Ordering Options

Pricing

Login for Your Price

Availability


Product Options

Packaging:
Color(s):
Length(s):
Quantity:
Units:
You might also consider these alternates:

Add to Cart

Have Tech Questions?
California Proposition 65

Product Overview

Features and Benefits

  • 20 AWG solid annealed bare copper center conductors
  • Gas-injected cellular polyethylene dielectric
  • 100% aluminum/poly/aluminum foil bonded to the dielectric
  • 95% tinned copper braided shield
  • Flexible opaque thermoplastic elastomer jacket
  • 4.5 GHz sweep, excellent SRL values
  • Non-UL for rack and interconnect, RoHS compliant

Applications

  • All analog and digital video formats
  • S/PDIF digital audio, line level RCA audio
  • Rack dressing, device to device, device to plate cabling

INTERFLEX-SD-BLK Summary

INTERFLEX-SD-BLK Diagrams

No available cross references for INTERFLEX-SD-BLK

Alternatives for INTERFLEX-SD-BLK

Part Number Description
IF-SD-BLK-100MINTERFLEX - Line Level Audio Non-Rated Cable for Interconnect Manufacture 100m Spool
18-CMR-VID
20-CMR-VID
INTERFLEX-SIAM

Download Hi-res Images


INTERFLEX-SD-BLK-End.psdINTERFLEX-SD-BLK-Front.psd

Specifications

PDF Spec Sheet

Product Line:   INTERFLEX
Description 20 AWG solid core dual shielded RG59 serial digital coaxial cable Non listed for interconnect manufacture. Product manufactured compliant to the requirements of UL444 for installations and applications in accordance with NEC articles 725, 800 and 820.
Component 1: 20 AWG
Solid annealed bare copper conductor
Diameter: 0.032" | 0.81mm
Electrical DC resistance: 10.5 Ω / 1000’ | 34.4 Ω/KM
Capacitance: 16.2 pF/FT | 53.14 pF/M
Impedance: 75 ± 3 Ω
Velocity of Propagation: 82%
Voltage rating: 300V
SRL 1-450 MHz: -26dB
SRL 451-850 MHz: -23dB
SRL 851-3.0 GHz: -18dB
Component 2: Foam polyethylene
Wall thickness: 0.057" | 1.45mm
Diameter: 0.144" | 3.66mm
Regulatory EU RoHS-2 2011/65/EU Compliant
Color Code Natural
Packages Reel: 328’ | 100M
Reel: 1000’ | 305M
Weight: 31 Lbs/1000’ | 47 Kg/KM
Assembly N/A
Installation Pull Tension: 37 Lbs | 165 N
Bend radius: 2.36" | 60mm unloaded
Bend radius: 4.72" | 120mm loaded
Construct N/A
Applications Serial Digital Video (SMPTE)
CATV and DBS modulated video
Baseband video signals
Digital audio unbalanced formats
Shield 100% aluminum/poly tape
95% 16x9/36 AWG tinned copper braid shield
Performance 3G HDSDI to 213 feet
CATV to 102 feet
CCTV to 449 feet
S/PDIF digital audio 420 feet
Jacket Transluscent Flame rated polyvinyl chloride
Colors: Black, Blue, Clear, Green, Orange, Red, White, Yellow
Wall thickness: 0.032" | .81mm
Diameter: 0.236" | 6.00mm
Final Outside Diameter (inches) 0.236
